Fischer Technical PILOT3000 Vacuum Pumps
About this item
This laboratory vacuum pump is library-quiet, small, durable, and chemical resistant.
- Diaphragm membrane rated for 15,000 hours use
- Liquid inlet trap with ball check valve
- Compact and portable at <10 lbs.
- Low noise volume ~ 54 dB
The PILOT3000 is nearly maintenance-free, with PTFE coated surfaces, PTFE membrane, stainless steel valves, and an oil-free design. PTFE surfaces make it resistant to bleach and acetone vapors, allowing it to be used with cell culture decontamination protocols. The pump is perfect for many applications, such as: vacuum filtration, solid phase extraction, desiccation, microbiology, aspiration, degassing, and fume suction.
The PILOT3000 is equipped with a 1/7 hp motor and provides a maximum 20 L/min (115 V/60 Hz) of free air displacement and 22 in-Hg of maximum vacuum. The pump features a vacuum regulator with gauge to adjust and monitor vacuum level. The inlet catch-pot protects from accidental ingestion of water and particulates.
Product Details
This laboratory vacuum pump is library-quiet, small, durable, and chemical resistant.
- Diaphragm membrane rated for 15,000 hours use
- Liquid inlet trap with ball check valve
- Compact and portable at <10 lbs.
- Low noise volume ~ 54 dB
The PILOT3000 is nearly maintenance-free, with PTFE coated surfaces, PTFE membrane, stainless steel valves, and an oil-free design. PTFE surfaces make it resistant to bleach and acetone vapors, allowing it to be used with cell culture decontamination protocols. The pump is perfect for many applications, such as: vacuum filtration, solid phase extraction, desiccation, microbiology, aspiration, degassing, and fume suction.
The PILOT3000 is equipped with a 1/7 hp motor and provides a maximum 20 L/min (115 V/60 Hz) of free air displacement and 22 in-Hg of maximum vacuum. The pump features a vacuum regulator with gauge to adjust and monitor vacuum level. The inlet catch-pot protects from accidental ingestion of water and particulates.
Specifications for Product Family
Specifications
- Catalog No:
- 470352-520
- Hose Connection:
- ¼" hose barb
- Weight:
- 3.9 kg (8.6 lbs.)
- Ultimate Vacuum:
- 190 mm Hg (75%), abs. (max. vacuum)
Specifications
Catalog No | Hose Connection | ¼" hose barb | Weight | 3.9 kg (8.6 lbs.) | Ultimate Vacuum | 190 mm Hg (75%), abs. (max. vacuum) |
|---|
Product Family Options
Product Information
- Free air capacityAvailabilityPrice
- 470352-520PILOT3000 diaphragm vacuum pump20 L/min (0.7 CFM), displacementIn Stock at VWREach$731.75 / EachIn Stock at VWR$731.75Each$731.7520 L/min (0.7 CFM), displacementSupplier Number: TLD3000Specifications:
More
- 470352-510PILOT pump vacuum regulator kit—On OrderEach$226.65 / EachOn Order$226.65Each$226.65—Supplier Number: TLD3500K-05Specifications:
More
- 470352-518PILOT pump pressure regulator kit—On OrderEach$226.70 / EachOn Order$226.70Each$226.70—Supplier Number: TLD3500K-06Specifications:
More
Accessories
Product Information
- AvailabilityPrice
- 470352-514PILOT3000 replacement diaphragmOn OrderEach$63.50 / EachOn Order$63.50
Product Information
- AvailabilityPrice
- 470352-512PILOT pump replacement feetOn OrderEach$119.45 / EachOn Order$119.45
Product Information
- AvailabilityPrice
- 470352-526PILOT3000 rebuild kitOn OrderEach$159.00 / EachOn Order$159.00
